Product advantage

1.Solves the pain point of "weak load-bearing, poor precision and short service life" — Adopts special high-load lead screws, guide rail structures and imported bearings, with strong load-bearing capacity and high positioning precision, making the machine's rigidity, precision retention and reliability close to perfect.​
2.Addresses the problem of "design defects and insufficient performance" — Introduces advanced design concepts and scientific design methods to make up for the unavoidable shortcomings of traditional design and improve the comprehensive performance of the equipment.​
3.Resolves the issue of "low efficiency and poor consistency" — Fast and simple programming, supporting multi-axis concurrent linkage and rapid feed positioning, with bending efficiency, precision and consistency significantly better than traditional hydraulic bending machines.​
4.Overcomes the difficulty of "high pollution and high energy consumption" — No need for hydraulic oil, environmentally friendly and pollution-free; saves about 80% energy compared with traditional equipment, reducing production energy consumption costs.​

Product show

Product principle

High-precision transmission foundation — High-load lead screws, guide rails and imported bearings work together to ensure accurate positioning and stable load-bearing during equipment operation, providing transmission support for high-precision bending.​Efficient linkage bending — After the CNC system receives programming instructions, it controls the concurrent linkage of multiple axes, drives the bending mechanism to quickly feed and position, and accurately completes the sheet metal bending action, improving processing efficiency and consistency.​
Environmentally friendly and energy-saving operation — Adopts all-electric servo drive, no need for hydraulic oil circulation system, avoiding oil pollution; at the same time, through optimized energy consumption design, it significantly reduces energy consumption compared with traditional hydraulic bending machines, realizing an environmentally friendly and energy-saving processing process.

Technical specifications

Machine ModelLF-LT-3512LF-LT-6020LF-LT-6025
Bending Force35T60T60T
Bending Length1200mm2000mm2500mm
Distance Between Columns950mm1720mm2020mm
Throat Depth400mm410mm360mm
Opening Height430mm430mm450mm
Slide Tilt±30mm±30mm±30mm
Control SystemSL100-P4/6SL100-P4/6SL100-P4/6
